MAXCRETE 651

NON-SHRINK PATCHING GROUT
Description
Maxcrete 651 Non-Shrink Patching Grout is a high strength grout that consist of high quality Portland cement,
graded natural aggregate and shrinkage compensating additives. It requires only the addition of water to form a
stiff grout with plastic consistency to mold into shapes and patch cavities without formwork support.
Features
 Require only addition of water.
 Stiff consistency eliminating formwork support in vertical
applications.
 No bleeding.
 High early and ultimate strength.
 Good dimensional stability.
 Impact and vibration resistant.
 Chloride and iron free, non-toxic and non-corrosive.
Uses
 Repairing chips in columns and walls.
 Patching holes, voids and cavities.
 Floor topping.
 Nosing edges.
 Anchor bolts.
 Forming fillets and chamfers.
 Other non-shrinkage filling requirements.
 High strength application.

Mixing
 Maxcrete 651 : 25 kg
 Clean Water : 4.25 liter
Pour 4.0 liter of water into mixing container and slowly add Maxcrete 651 powder while stirring with an electrical
mixer at 500 rpm. Adjust to desired consistency by adding part portion of 0.25 liter water. Mix for 3 minutes until
lump free homogenous consistency.
Preparation
Concrete surfaces shall be clean, sound and free from contaminants, laitance and loose particles.
Iron and steel surfaces shall be free from scale, rust, oil and grease.
Absorbent substrates must be saturated thoroughly, leaving no standing water before grout placement.
Application
Holes, Voids & Cavities : Compact the freshly mixed grout into the repair area and finished with a steel trowel.
Large Cavity/Volume : To prevent over-heating, add aggregate at ratio of between 50-100% by weight of
Maxcrete 651 powder. Well graded aggregate up to 30mm can be used but it must not exceed 33% the size of
the minimum gap. The use of cold water to mix the grout will be beneficial in keeping temperature down during
initial cure.
Floor Topping : Premix 15 kg of sand (size: 2.5 – 5.0mm) to 25 kg Maxcrete 651. Dilute 3 liter Maxcrete Latex
with 3 liter clean water and slowly add the premixed of sand and grout. Stir with an electric mixer until
homogenous and lump free. Adjust to the desired consistency by adding more diluted latex or premix before
placement.
Curing
Protect from strong sunlight and high windy condition during curing.
Keep moist for the next 3 days.
Storage & Shelf Life
Keep elevated in dry, moisture free condition.
Can be stored for 12 months in sealed original packaging.
Health & Safety
Prevent contact with skin and wear waterproof gloves and googles when handling.
Upon contact with skin, wash with soap and water.
In case of eye contact, flush with water and seek medical attention immediately.
